SHJOY provides you with all specifications of top quality fully wrapped carbon fiber reinforced aluminum lined composite cylinder and composite cylinder for compressed hydrogen storage.
9L Carbon Fiber Wrapped Composite Cylinder
1)Outside diameter: 174mm
2)Water capacity: 9L
3)Height: 558mm
4)Weight: 4.9kgs
5)Working pressure: 30MPa
6)BurstingPressure: ≥102Mpa
7)Standard: 97/23/EC
Type | Outside Diameter (mm) | Water Capacity (L) | Working Pressure (MPa) | Bursting Pressure (MPa) | Standard |
CRP III-105-1.6-20-T | 1.6 | 115 | 20 | ≥68 | 97/23/EC |
CRP III-124-2.0-20-T | 2.0 | 130 | 20 | ≥68 | 97/23/EC |
CRP III-105-3.0-30-T | 3.0 | 114 | 30 | ≥102 | 97/23/EC |
CRP III-125-4.7-30-T | 4.7 | 137 | 30 | ≥102 | 97/23/EC |
CRP III-144-6.8-30-T | 6.8 | 157 | 30 | ≥102 | 97/23/EC |
CRP III-162-9.0-30-T | 9.0 | 174 | 30 | ≥102 | 97/23/EC |
CRP III-162-12.0-30-T | 12.0 | 205 | 30 | ≥102 | 97/23/EC |
